Glass Heat-Soak-Test Furnace with EVA lamination

Glass Heat-Soak-Test Furnace with EVA lamination
  • Heat-Soak-Test Furnace with EVA lamination
  • Heat-Soak-Test Furnace with EVA lamination
  • Heat-Soak-Test Furnace with EVA lamination
  • Heat-Soak-Test Furnace with EVA lamination
  • Heat-Soak-Test Furnace with EVA lamination
  • Heat-Soak-Test Furnace with EVA lamination
  • Heat-Soak-Test Furnace with EVA lamination
  • Heat-Soak-Test Furnace with EVA lamination
  • Heat-Soak-Test Furnace with EVA lamination
SPECIFICATION
Max. glass size: 2500x6000mm

The tempering glass heat soak test furnace is made as the Europe standard which is strengthen safety of glasses. Adopting solid state relay. The computer can record and control the parameters intelligently. Temperature control mode is auto completed by electronic control system, which based on PLC and Kingview. The temperature and the result can be record and print automatically each time. There are four sets of thermal cycle and the cooling fan (Frequency control), Strengthen circulation and convection , The furnace heating air from outside, To strengthen the cooling efficiency ,at the same time add two cooling balance fan to improve cooling speed, there are 20 thermocouples in the heat furnace body, can monitor temperature on surface of glasses from every area. Distribution of furnace top six thermocouple can monitor air temperature in the furnace

Standart: BS EN 14179-1:2016 and BS EN 14179-1:2005

Convection type: single convection
