Vertical glass drilling and milling machine is a five-axis composite CNC working center which is designed for drilling hole, milling notches, cut-outs, grinding, countersinking and polishing on all regular and most irregular glass sheet with thickness of 4-25mm. The machine is controlled by a high-end numerical control operating system to achieve precise control of each servo axis. This flexibility of the control system can meet the requirement of different products. Combined with the structure of high rigidity and high stability, glass processing in high-speed and high-precision can be easily implemented.

This machine is a perfect choice for glass processing factories. All work can be processed automatically and the complicated jobs can be performed in quick speed and high efficiency with smallest investment. Thanks to the self-developed CAM software, many powerful functions can be used. It can automatically generate processing technology for different processing graphics, and generate processing programs according to specific processes. Same time, it also has auxiliary functions such as library management and tool library management, which greatly reduces the heavy processing operations, making it so easy to operate.

The vertical drilling and milling machine is a good solution for decoration glass, bathroom glass, building glass (frameless shower door, glass curtain wall, balustrade)...

1. Double electric-spindles with central water cooling. Holes can be drilled by two opposite heads so that the drilling speed and quality can be better ensured;

2. Thanks to the beckhoff system, the front and back spindles can mill and grind at same time if the two cutouts on the same side same vertical straight line, which can greatly improve processing speed;

3. Automatically tool change through 7+7 tool magazine. All complicated and heavy operation can be implemented in high efficiency automatically;

4. Designed in vertical direction which occupies less area and is convenient to load and unload glass sheet, especially for big architectural glass

5. Glass processing line is easily connected. Vertical drilling＆milling＆washing processing line can be composed of PALZX-2530 and vertical washing machine. Only one operator is required for the whole vertical line;

6. Provide private customized service to meet different product requirements. Such as different machine dimensions, glass input-output directions and so on...

7. More than 40 common graphics are created in the graphics library. Easy to learn, no need CAD skill;

8. DXF can be read as alternative;
